#0389 – SQL Server – SSIS – OLE DB Destination – Table Fast Load – Keep NULLs option


SQL Server Integration Services (SSIS) are typically called upon when integrating systems exchange data from one source to a given destination. The reason I use the term “source” and “destination” instead of a “database” because either of the two can be something other than a database (a flat file, some web-service, a script task, etc). This is possible because SSIS is more like any other .net framework based programming language (C# or VB.net).

OLE DB destination

Because one would commonly have either a Microsoft Access or a Microsoft SQL Server on at least one side of the integration, the most common source & destinations used in a SSIS-based data solution are the OLE DB Source and the OLE DB Destination. The OLE DB destination allows you to load data to a table, a view or even a SQL command (e.g. the results of a statement execution).

In order to load data as quickly into the destination as possible, the  OLE DB destination allows us to use a “Fast Load” mode. The “Fast Load” option allows the data team to configure various options that affect the speed of the data load:

  1. Keep Identity
  2. Keep NULLs
  3. Table Lock
  4. Check Constraints
  5. Rows per Batch
  6. Maximum Insert Commit Size

We will look at each option in detail over the next couple of weeks.

Keep NULLs option

The Keep NULLs option is normally something that most accidental SSIS developers do not pay much attention to. It comes unchecked by default and it left unchecked. However, the state of this checkbox can have a significant impact on the completeness and quality of data being inserted into the destination database.

To clarify, allow me to explain the functionality of this checkbox:

  1. Checked – If a column in the source data has NULL values, keep them as-is
  2. Unchecked – If a column in the source data has NULL values, try to replace them with the default values as defined by the destination DB

The state of this checkbox typically does not make much of a difference because in most cases, the domain and business rules in both the systems involved would be similar. Thus, the if a column in one system allows a NULL value, other systems in the same domain would also allow a NULL (e.g. in most enrollment forms, the last name would generally be mandatory but the first name is not). However, legacy systems (which have been around since decades) would have accumulated a lot data that does not conform to newer domain practices, causing issues during migration. This is when the “Keep Nulls” checkbox comes into action.

In the case I am going to present today, I have a set of Product Names and their corresponding Manufacturers. In a few of these cases, I don’t know the manufacturer and have therefore kept it blank.

USE tempdb;
GO
--Test Data
SELECT [ProductList].[ProductName],
       [ProductList].[ManufacturerName]
FROM (VALUES ('Windows'     , 'Microsoft'),
             ('SQL Server'  , NULL       ),
             ('VisualStudio','Microsoft'),
             ('MySQL'       , 'Oracle'   ),
             ('PeopleSoft'  , 'Oracle'   )
     ) AS [ProductList] ([ProductName], [ManufacturerName]);
GO
Sample data with some NULL values

Sample data with some NULL values

For the sake of this demo, I have used this query as my source in the test SSIS package. Below is a screenshot of my data flow task.

Using a test data query in the OLE DB source command

Using a test data query in the OLE DB source command

I directly take this dataset as input to the OLE DB destination. The OLE DB destination is configured to a test table ([dbo].[KeepNullsInOLEDB]) with the following table definition.

USE [tempdb];
GO
--Safety Check
IF OBJECT_ID('dbo.KeepNullsInOLEDB','U') IS NOT NULL
BEGIN
    DROP TABLE dbo.KeepNullsInOLEDB;
END
GO

--Create table
CREATE TABLE dbo.KeepNullsInOLEDB
        ([ProductName]      VARCHAR(255) NULL,
         [ManufacturerName] VARCHAR(255) NULL
                            CONSTRAINT df_KeepNullsInOLEDB_ManufacturerName
                            DEFAULT ('Microsoft')
        );
GO

OLE DB Destination Configuration. Notice the “Keep nulls” switch is unchecked.

After executing the package, I query the [dbo].[KeepNullsInOLEDB] table in the destination database, and compare with the source data.

Values inserted into the destination table. Notice the default value from table definition is used.

Values inserted into the destination table. Notice the default value from table definition is used.

As can be seen from the screenshot, the [ManufacturerName] for “SQL Server” is not NULL. It is instead set to “Microsoft” which is the default value as set in the default constraint on the destination table.

The data inserted in the destination table changes if the switch is kept checked in the OLE DB destination.

Notice how the value from the default constraint is not used when “Keep Nulls” is checked.

If the “Keep nulls” checkbox is checked, the default constraint on the target table is not used – thereby maintaining the same data as the source.

Summary

Depending upon the business requirements, it may be critical to migrate data from a source to a destination “as-is”, without the application of default constraints. In such situations, the “Keep nulls” switch on the OLE DB destination (“Fast Load” mode) needs to be checked.

If the “Keep nulls” switch is unchecked, the default constraints from the target table definition come into effect.

In my future posts, I will take a look at the other switches on the OLE DB Fast Load mode.

Until we meet next time,

Be courteous. Drive responsibly.

Advertisements
Data Flow Task used to demonstrate case-sensitivity of Lookup transformation

#0388 – SQL Server – SSIS – Lookup transformations are case-sensitive


I have been working with SQL Server Integration Services (SSIS) recently. In many ways, SSIS is counter-intuitive if you have been working with the database engine for long (more than a decade in my case). Working with SSIS is more like working with any other .net framework based programming language (C# or VB.net). Over the next couple of days, I will be writing about some of the salient aspects of SSIS which should be kept in mind in case you are working on multiple SQL Server technologies.

Lookup Transformations – A key to successful system integrations

Cross-referencing of Enumerations

One of the key challenges for any system integration is to ensure that the enumerations  and “default” values used in the source system (e.g. sales statuses, product categories, etc) align between the “source” & “target” systems.

Once the values aligned during business, high-level and low-level designs, implementation of this cross-referencing in SQL Server Integration Services (SSIS) is done by a data flow component called the “Lookup Transformation“. The Lookup transformation effectively performs a join between the input data with a reference data set. If values match, they are available in what is called the “Match Output” whereas values that do not match can be made available as a “No Match Output”. However, this comes with a tiny counter-intuitive behaviour that I learnt about the hard way.

The lookup performed by the lookup transformation is case-sensitive.

Demo

In order to demonstrate the case-sensitivity of lookup transformations, I have developed a SSIS package that does the following in a simple data-flow task:

  1. Get some static data from an OLEDB data source, basically some rows with text representation of numbers (One, Two, Three, and so on)
  2. The Lookup transform has a static mapping between the numeric and text values of various numbers – 1 through 10
  3. As the input data passes through the lookup transformation, we try to map the text values in the source data with the values available in the lookup transformation so that we can get the appropriate numeric representation
    • In my demo, records that find a valid lookup are written to a recordset destination (it could be any valid destination), whereas records that do not match are written to another destination
    • I have placed data viewers on the output pipelines to visually see the data being moved, which is what I will show below

The query used to generate the static data in the OLE DB source is provided below.

SELECT srcValues.RowName,
       srcValues.RowValue
FROM (VALUES ('Row1','One'),
             ('Row2','Two'),
             ('Row3','three'),
             ('Row4','Four'),
             ('Row5','Five'),
             ('Row6','Six'),
             ('Row7','seven'),
             ('Row8','eight'),
             ('Row9','Nine'),
             ('Row10','Ten')
     ) AS srcValues (RowName, RowValue);

The query used to generate the lookup values for the lookup transform is provided below:

SELECT lookUpValues.Id,
       lookUpValues.RowValue
FROM (VALUES (1, 'One'),
             (2, 'Two'),
             (3, 'Three'),
             (4, 'Four'),
             (5, 'Five'),
             (6, 'Six'),
             (7, 'Seven'),
             (8, 'Eight'),
             (9, 'Nine'),
             (10, 'Ten')
     ) AS lookUpValues (Id, RowValue);

Observe that in the static source data, not all values have a consistent case – some are in sentence case, whereas some are in small case.

The screenshots below show the overall setup of the SSIS package.

Data Flow Task used to demonstrate case-sensitivity of Lookup transformation

Data Flow Task used to demonstrate case-sensitivity of Lookup transformation

LookUp Transformation - General configuration (Notice redirection to no match output)

LookUp Transformation – General configuration (Notice redirection to no match output)

Lookup Transformation - Connection tab showing reference values

Lookup Transformation – Connection tab showing reference values

Lookup Transformation - Columns configuration showing "RowValue" used for matching whereas the reference Id is fetched to include in output

Lookup Transformation – Columns configuration

Notice here that we have used the text value from the source data (“RowValue” column) for matching/lookup to the reference data set. The reference Id is fetched to include in output.

If a match is found the “Match Output” should contain the matching row from the source combined with the Id from the reference/lookup data. This is seen in the data viewer output below.

Lookup Transformation - Match Output (source rows with the Id from the reference data)

Lookup Transformation – Match Output (source rows with the Id from the reference data)

If a match is not found (which would be the case for the values with lower case in the source data), the “No Match Output” will contain the row from the source data that failed the lookup (since failures were redirected to the “No Match” output in the general configuration). Notice we do not get the Id from the reference because no match to the reference was found.

Lookup Transformation - No Match Output

Lookup Transformation – No Match Output

Summary

When working with a case insensitive database, we often tend to take data quality with respect to case of the data for granted. Having data with inconsistent case has multiple repercussions (especially with data grouping in front end applications), but the biggest negative impact due to inconsistent case of text data is the inaccurate cross-referencing during a master data cleanup, system integration or data migration exercise.

Call to action

Do take a few cycles in your development to take a look at your data quality, and if necessary, implement required data cleansing to ensure that your lookup data, enumerations and master data are using a case that is correct and consistent with the domain and business requirements.

Until we meet next time,

Be courteous. Drive responsibly.
